| MULTIPOLARES | ||||||||
SECCIÓN NOMINAL | DIÁMETRO EXTERIOR APROXIMADO | ESPESOR PROMEDIO VAINA EXT. | ESPESOR PROMEDIO CONDUCTOR | PESO TOTAL APROX. | CORRIENTE ADMISIBLE | CAÍDA DE TENSIÓN | COLORES CONDUCTORES | |
| ENTERRADO | AL AIRE/BANDEJA | |||||||
| mm2 | mm | mm | mm | Kg/100m | Amperes | V/km | ||
| 2X1,50 | 924 | 180 | 80 | 12,124 | 29 | 16 | 2,100 | 2 conductores Marrón-Celeste |
| 2X2,50 | 1,066 | 180 | 80 | 16,599 | 39 | 22 | 1,300 | |
| 2X4 | 1,276 | 180 | 100 | 24,297 | 51 | 30 | 861 | |
| 2X6 | 1,364 | 180 | 100 | 29,602 | 65 | 37 | 577 | |
| 2X10 | 1,581 | 180 | 100 | 42,397 | 88 | 52 | 337 | |
| 2X16 | 1,924 | 180 | 100 | 65,298 | 112 | 70 | 216 | |
| 2X25 | 2,200 | 180 | 120 | 88,778 | 144 | 88 | 134 | |
| 3X1,50 | 1,000 | 180 | 80 | 14,871 | 29 | 16 | 2,100 | 3 conductores Marrón-Negro-Rojo/ Marrón-Celeste- PE(V.Am.) |
| 3X2,50 | 1,170 | 180 | 80 | 20,915 | 39 | 22 | 1,300 | |
| 3X4 | 1,313 | 180 | 100 | 27,975 | 51 | 30 | 861 | |
| 3X6 | 1,395 | 180 | 100 | 34,427 | 65 | 37 | 577 | |
| 3X10 | 1,580 | 180 | 100 | 48,798 | 88 | 52 | 337 | |
| 4X1,50 | 1,043 | 180 | 80 | 16,769 | 29 | 16 | 2,100 | 4 conductores Marrón-Negro- Rojo-Celeste |
| 4X2,50 | 1,228 | 180 | 80 | 23,880 | 39 | 22 | 1,300 | |
| 4X4 | 1,428 | 180 | 100 | 33,807 | 51 | 30 | 861 | |
| 4X6 | 1,613 | 180 | 100 | 45,366 | 65 | 37 | 577 | |
| 4X10 | 1,875 | 180 | 100 | 66,324 | 88 | 52 | 337 | |
| 4X16 | 2,205 | 180 | 100 | 99,446 | 112 | 70 | 216 | |
| 3X25+16 | 2,660 | 180 | 1,20/1,00 | 136,393 | 144 | 88 | 134 | |
| 3X35+16 | 3,030 | 180 | 1,20/1,00 | 173,619 | 173 | 110 | 98 | |
| 3X50+25 | 3,550 | 190 | 1,40/1,20 | 198,500 | 207 | 133 | 74 | |
| 3X70+35 | 3,900 | 200 | 1,40/1,20 | 317,800 | 254 | 170 | 54 | |
| 3X95+50 | 4,300 | 220 | 1,60/1,40 | 34,500 | 306 | 207 | 41 | |
| 4X1,50+PE | 1,188 | 180 | 80 | 21,211 | 29 | 16 | 2,100 | 5 conductores Marrón-Negro- Rojo-Celeste- PE(V.Am.) |
| 4X2,50+PE 4X4+PE 4X6+PE | 1,364 | 180 | 80 | 29,024 | 39 | 22 | 1,300 | |
| 15,36 16,55 | 1,80 1,80 | 1,00 1,00 | 39,246 49,695 | 5165 | 3037 | 8,61 5,77 | ||
| 4X10+PE | 1,983 | 180 | 100 | 75,984 | 88 | 52 | 337 | |
