Aerial Bundled Conductor Low Voltage XLPE Insulated

2025-11-27 17:04
Aerial Bundled Conductor (ABC) with Low Voltage XLPE Insulation is a compact overhead power distribution solution designed for low voltage networks.

AERIAL BUNDLED CONDUCTOR LOW VOLTAGE XLPE  INSULATED



Application

Used for overhead power transmission and distribution projects.

Aerial Bundled Conductor (ABC) with Low Voltage XLPE Insulation is a compact overhead power distribution solution designed for low voltage networks. It provides excellent electrical performance, insulation, and resistance to environmental stress, ensuring safer and more reliable power transmission.



Construction

Hard Drawn Aluminium  Phase Conductor around an aluminium Alloy Suppporting Core, Insulated with Carbon loaded Cross Linked Polyethylene(XLPE), Additional sub-conductors optional in both self -supporting and

supporting core System.



Phase Conductors

The material of Phase, Neutral and auxiliary conductors hard drawn Aluminium wire, which has tensile strength, before stranding minimum 140MPa and maximum 225 MPa


Supporting Conductors

A supporting  conductor construced aluminium-magnesium-silicon alloy wires, which has tensile strength,

before stranding minimum 295 MPa and with modulus of elasticity 59000 MPa, coeffiecent of linear expansion 23 x 10-6  /°C .


Insulation

Insulation material cross-linked polyethylene (XLPE) type- C, requirements as per SANS 1411-4 with contain at least 2.5% carbon black.


Standard

Low Voltage Aerial Bundled Conductor XLPE Insulated SANS-1418 Part 1 & 2.




PHYSICAL PROPERTIES FOR AERIAL BUNDLED CONDUCTOR

Catalouge

Number

Type of

Conductor

Nominal

Cross

Sectrion

Area

Number of

Wire in

Conductor

Max.

Diameter of

Conductor

Nominal

Thickness

of

Insulation

Core

Diameter

Approx

Cable

Diameter

Approx

Cable

Weight



LV ABC CABLE







Phase,

Auxiliary or

Non-Strain-

bearing

Neutral

(Aluminium)

SQ.MM

Nos.

MM

MM

MM

MM

Kg/MM

25

35

50

70

95

120

150

7

7

7

19

19

19

19

6.3

7.3

8.4

10.2

12.0

13.5

15.0

1.4

1.6

1.6

1.8

1.8

1.8

1.8

9.4

10.9

12.0

14.2

16.0

17.5

18.6

26

28

32

36

38

42

48

507

612

730

945

1185

1610

1880





--

Service

Connection

(Aluminium)

16

25

7

7

5.3

6.6

1.2

1.4

8.0

9.6

--

--

--

--

Supporting

(Aluminium

Alloy)

54.6

70

7

7

9.6

10.4

1.6

1.6

13.0

13.6

--

--

--

--

ELECTRICAL & MECHANICAL PROPERTIES

Nominal Cross

Section Area



Breaking Load

Max. Conductor

Resistance at 20°C

Insulation Dielectric Resistance at 20°C

Permissible Current

Rating

Phase Conductor

SQ.MM

N

Ohm/Km

MΩ/km

Amp

25

3300

1.20

50

122

35

4500

0.868

50

138

50

6200

0.641

50

168

70

8900

0.443

50

213

95

12300

0.320

50

258

120

15600

0.253

50

298

150

19200

0.206

50

332

16

2070

1.91

50

--

25

3300

1.20

50

--

54.6 (Alloy Cond.)

16600

0.63

50

--

70 (Alloy Cond.)

20100

0.50

50

--
